Texas Instruments ADS1015IRUGR 12-Bit Delta-Sigma ADC – I2C, PGA, 3.3k SPS, -40°C to 125°C

Product Attributes – Texas Instruments ADS1015IRUGR

 Category

Integrated Circuit (IC) Specifically designed for Data Acquisition applications Analog-to-Digital Converter (ADC)

Manufacturer

Texas Instruments

Packaging

Available in Tape & Reel (TR), Cut Tape (CT), and Digi-Reel® (DigiKey’s custom tape solution)

Part Status

Actively in stock and available for purchase

Technical Specifications

Resolution: 12-bit precision for accurate analog-to-digital conversion

Sampling Rate: 3.3k samples per second (SPS)

Input Channels: Supports 2 or 4 channels, configurable for differential or single-ended input types

Data Interface: I2C (Inter-Integrated Circuit) serial communication for easy integration

Configuration: Combines a Multiplexer (MUX), Programmable Gain Amplifier (PGA), and ADC (MUX-PGA-ADC) for flexible signal processing

Conversion Architecture: Delta-Sigma (Δ-Σ) for high-resolution performance

Reference Type: Internal voltage reference, eliminating the need for external components

Supply Voltage: 2V to 5.5V (both analog and digital)
