Name: 16-Bit SAR ADC.ADI MAX11644EUA+T , 4-Channel, SPI, 100ksps, 2.7-5.25V, TSSOP-16
Brand: Analog Devices Inc./Maxim Integrated
SKU: 11112
Availability: InStock

16-Bit SAR ADC.ADI MAX11644EUA+T , 4-Channel, SPI, 100ksps, 2.7-5.25V, TSSOP-16

$3.39

Product Brief Description (English): The ADI MAX11644EUA+T is a 16-bit successive approximation register (SAR) analog-to-digital converter (ADC) designed for high-precision multi-channel data acquisition. Featuring 4 single-ended input channels, it enables simultaneous conversion of analog signals with 65,536-level resolution, ideal for sensor interfaces in industrial, medical, and instrumentation systems. Equipped with a high-speed SPI interface, the ADC supports up to 100 ksps sampling rate for real-time data capture. It operates from a single 2.7–5.25V supply, offering flexibility with external or internal voltage reference (2.5V typical). The device consumes only 1.3mA in active mode and <1μA in standby, making it suitable for battery-powered applications. Housed in a compact TSSOP-16 package, the MAX11644EUA+T ensures reliable performance across -40°C to +85°C, supporting applications such as precision measurement systems, motor control, and multi-channel data logging in harsh environments.

Description

Product Attributes Description (English)

Category Integrated Circuits (ICs) Data Acquisition Analog-to-Digital Converters (ADCs)

Manufacturer Analog Devices Inc./Maxim Integrated

Series N/A

Packaging Tape & Reel (TR) Cut Tape (CT) Digi-Reel® (Digi-Key Custom Tape)

Part Status Active (In Stock)

Resolution (Bits) 12-bit Total digital values: 2¹² = 4,096 levels

Sampling Rate 94.4 ksps (kilo samples per second)

Number of Inputs 1 or 2 channels (configurable)

Input Type Differential and Single-Ended Input range: Dependent on reference (external/internal)

Data Interface I2C (Inter-Integrated Circuit)

Configuration MUX-S/H-ADC (Multiplexer-Sample/Hold-Analog-to-Digital Converter)

Ratio – S/H:ADC 1:1

Number of A/D Converters 1

Architecture SAR (Successive Approximation Register)

Reference Type External and Internal (optional)

Supply Voltage – Analog 5V

Supply Voltage – Digital 5V

Features N/A (No specific additional features noted)

Operating Temperature Range -40°C to +85°C

Package / Case 8-TSSOP (Thin Shrink Small Outline Package), 8-MSOP (Micro Small Outline Package) Dimensions: 0.118″ (3.00mm) width Supplier Device Package: 8-uMAX/uSOP

Mounting Type Surface Mount

Base Product Number MAX11644
