Microchip MCP3561-E/ST 24-Bit Sigma-Delta ADC with 153.6 kSPS, SPI Interface, TSSOP-20 Package

Product Attributes Description (English)

Category Integrated Circuits (ICs) Data Acquisition Analog to Digital Converters (ADCs)

Manufacturer Microchip Technology

Series N/A

Packaging Tube

Part Status Active

Resolution (Bits) 24-bit

Sampling Rate 153.6 kSPS (kilo samples per second)

Number of Inputs 1 or 2 channels

Input Type Differential and Single-Ended

Data Interface SPI (Serial Peripheral Interface)

Configuration N/A

Ratio – S/H:ADC N/A

Number of A/D Converters 1 channel

Architecture Sigma-Delta (Δ-Σ)

Reference Type N/A

Supply Voltage – Analog 2.7V to 3.6V

Supply Voltage – Digital 1.8V to 3.7V

Features Internal Oscillator PGA (Programmable Gain Amplifier) Integrated Temperature Sensor

Operating Temperature Range -40°C to +125°C

Package / Case 20-TSSOP (Thin Shrink Small Outline Package), 0.173″ (4.40mm) width

Supplier Package 20-TSSOP

Mounting Type Surface Mount Technology (SMT)

Base Product Number MCP3561
