Product Overview
The ADC081C021CIMKX/NOPB is a high-performance 8-bit Analog-to-Digital Converter (ADC) designed by Texas Instruments (TI). Engineered for industrial and embedded applications, this device combines precision, low power consumption, and a compact form factor. With an I²C-compatible interface and industrial temperature range (-40°C to 105°C), it excels in harsh environments while delivering reliable data conversion.
Key Features
-
High Accuracy:
- 8-bit resolution with ±0.2 LSB INL/DNL (Integral/Differential Nonlinearity) ensures precise analog-to-digital conversion .
- 49.8 dB SNR (Signal-to-Noise Ratio) minimizes noise interference in critical applications .
-
Speed & Efficiency:
- 189 kSPS (kilo-samples per second) throughput for high-speed data acquisition .
- Low power consumption: 0.26 mW at 3V supply (typ), ideal for battery-powered systems .
-
Flexible Operation:
- Single-supply operation (2.7V to 5.5V) simplifies circuit design.
- Single-ended input configuration supports unipolar signals up to 5.5V .
-
Compact Packaging:
- SOT-23-THN (DDC) 6-pin package (CIMKX suffix) for space-constrained designs .
- Tape & Reel (NOPB) packaging ensures automated pick-and-place assembly readiness .
-
Enhanced Reliability:
- Industrial temperature range (-40°C to 105°C) for robust performance in extreme conditions.
- ±8 kV HBM ESD protection on I²C pins (SDA/SCL) .
