Name: Microchip MCP3208-CI/SL 12-Bit 8-Channel SAR ADC 100kSPS SPI Interface 2.7V-5.5V SOIC-16 RoHS AEC-Q100
SKU: 11386
Availability: InStock

Microchip MCP3208-CI/SL 12-Bit 8-Channel SAR ADC 100kSPS SPI Interface 2.7V-5.5V SOIC-16 RoHS AEC-Q100

$4.60

The MCP3208 is a 12-bit successive approximation register (SAR) analog-to-digital converter (ADC) from Microchip Technology, designed for data acquisition systems. It features 4 to 8 input channels with pseudodifferential or single-ended input types, supporting a sampling rate of up to 100k samples per second. The device uses an external reference and connects via SPI interface, ideal for multiplexed sample-and-hold applications with a 1:1 S/H:ADC ratio. Operating over 2.7V to 5.5V analog/digital supplies, it withstands -40°C to 85°C and comes in a 16-SOIC surface-mount package, currently active in the market

Description

Product Attributes of MCP3208

Category Integrated Circuit (IC), Data Acquisition, Analog-to-Digital Converter (ADC)

Manufacturer Microchip Technology

Packaging Tube

Part Status Active

Resolution (Bits) 12-bit

Sampling Rate 100k samples per second

Number of Inputs 4 or 8 channels

Input Type Pseudodifferential, Single-Ended

Data Interface SPI (Serial Peripheral Interface)

Configuration MUX-S/H-ADC (Multiplexer-Sample/Hold-ADC)

Ratio – S/H:ADC 1:1

Number of A/D Converters 1

Architecture SAR (Successive Approximation Register)

Reference Type External

Supply Voltage – Analog 2.7V ~ 5.5V

Supply Voltage – Digital 2.7V ~ 5.5V

Operating Temperature Range -40°C ~ 85°C

Package/Case 16-SOIC (0.154″, 3.90mm Width)

Supplier Device Package 16-SOIC

Mounting Type Surface Mount

Basic Product Number MCP3208
